Auto Credit Based on Probreyene's Falcon 9 Block 5 [p04.s2]

This is not the final replica but heres the real world description:


FALCON HEAVY

Falcon Heavy is the most powerful operational rocket in the world by a factor of two. With the ability to lift into orbit nearly 64 metric tons (141,000 lb)---a mass greater than a 737 jetliner loaded with passengers, crew, luggage and fuel--Falcon Heavy can lift more than twice the payload of the next closest operational vehicle, the Delta IV Heavy, at one-third the cost. Falcon Heavy draws upon the proven heritage and reliability of Falcon 9.

Its first stage is composed of three Falcon 9 nine-engine cores whose 27 Merlin engines together generate more than 5 million pounds of thrust at liftoff, equal to approximately eighteen 747 aircraft. Only the Saturn V moon rocket, last flown in 1973, delivered more payload to orbit. Falcon Heavy was designed from the outset to carry humans into space and restores the possibility of flying missions with crew to the Moon or Mars.


SECOND STAGE

THRUST 934 kN
BURN TIME ~400 sec

FIRST STAGE

THRUST AT SEA LEVEL 22,819 kN
THRUST AT VACUUM 24,681 kN

TECHNICAL OVERVIEW

HEIGHT 70 m
TOTAL WIDTH 12.2 m
STAGES 2
BOOSTERS 2
MASS 1,420,788 kg
PAYLOAD TO LEO 63,800 kg
PAYLOAD TO GTO 26,700 kg
PAYLOAD TO MARS 16,800 kg
PAYLOAD TO PLUTO 3,500 kg

Falcon Heavy Reference


Falcon Heavy Bottom View


Falcon Heavy Website

GENERAL INFO

  • Predecessor: Falcon 9 Block 5 [p04.s2]
  • Created On: Windows
  • Game Version: 0.8.200.0
  • Price: $39,284k
  • Number of Parts: 706
  • Dimensions: 70 m x 14 m x 6 m

PERFORMANCE

  • Total Delta V: 44.9km/s
  • Total Thrust: 12.7MN
  • Engines: 28
  • Wet Mass: 6.24E+5kg
  • Dry Mass: -138,568kg

STAGES

Stage Engines Delta V Thrust Burn Mass
1 27 40.8km/s 12.1MN 2.8m 6.24E+5kg
4 1 4.2km/s 518kN 5.3m 69,061kg

10 Comments

  • Log in to leave a comment
  • Profile image
    6,445 Probreyene

    @DUNIAN it is possible but risky without vizzy at the moment

    +1 3.6 years ago
  • Profile image
    773 DUNIAN

    Can you land Both side booster?

    +1 3.6 years ago
  • Profile image
    6,445 Probreyene

    @TheProrocket its too late for a reply but im still going back from zero since i took a break (when vizzy came out) and forgot the way its built but im looking forward to making rockets again and i will be back and better with vizzy

    +1 3.8 years ago
  • Profile image

    You can made a Auto-landing in the boosters

    4.0 years ago
  • Profile image

    @Probreyene https://www.simplerockets.com/c/3355t1/Falcon-Heavy-Stage-2

    +2 4.2 years ago
  • Profile image

    @Probreyene Kay.

    4.2 years ago
  • Profile image
    6,445 Probreyene

    @epickoolman789 Sure
    But it needs to have the correct measurements (or at least be acceptable) to be included in my next builds.

    4.2 years ago
  • Profile image

    Can I make a custom fairing for you with the logos?

    4.2 years ago
  • Profile image
    6,445 Probreyene

    Update: i have the retractable separator in the middle of the ship above done (connection from left booster to right)
    And i have updated the landing legs to be made by struts
    And uhh ill try to redo the grid fins for a real real replica

    This is not for mobile users actually so sorry about that ill just make a smaller version with simplified parts

    4.6 years ago
  • Profile image
    6,445 Probreyene

    For those people who are wondering if its functioning properly now it is. Its not wobbly compared to HV1 and HV2. The design is incomplete but the thing is that it flies.

    4.6 years ago
