Auto Credit Based on Alxucm's BlackAtlas V1

After a bit of fixing, I present to you the BlackAtlas V1.1
In first stage, it contains 52 Forge engines, 2 sets of RCS’s below the interstage, and 4 Merlin legs for a soft landing.
In the second stage, it contains 27 Forge engines, one fully customizable payload deploying/sheiding mechanism.

Notes: due to low TWR ratio at first stage, you need to start the gravity turn fairly late, and the landing burn fairly early.
due to high TWR ratio at the second stage, you probably need to throttle down a bit when inserting to orbit.
if doing the landing, cut the first stage engine when 10-15% fuel is left.
second stage is fairly ez to flip over inside the adtomosphere, so pay attention to the second stage and dont cut the engine inside the adtomosphere.
Payload range: About 0-25T ( Reusing, Leo)
The rocket is designed for Low earth(Droo) orbit and Median earth(Droo) orbit.
BTW: the staging is incorrect, use AG’s instead.
AG: outer ring, the outermost engine of the forst stage.
Leg: landing leg of the first stage
Sep, seperates stage one and two, and ignites the second stage engine.
median ring: the second ring of the first stage engine(out to center)
inner ring: the innermost ring of the first stage engine
center: center of the first stage engine
rcs: rcs turusters.

improvements: fixed the engine names
                  added more cams
                  added a dummy payload

Known bugs(As of the post): The second stage would enter a spin upon stage seperation, this can be partially fixed by switching to it and throttle to 100%(currently unknown how to fix it)

let me know if you encountered any more bugs in the comments, and I will attempt to fix it.
Hope you enjoy the craft!

GENERAL INFO

  • Predecessor: BlackAtlas V1
  • Created On: iOS
  • Game Version: 1.3.204.1
  • Price: $186,891k
  • Number of Parts: 125
  • Dimensions: 101 m x 12 m x 12 m

PERFORMANCE

  • Total Delta V: 8.6km/s
  • Total Thrust: 42.5MN
  • Engines: 79
  • Wet Mass: 2.42E+6kg
  • Dry Mass: 1.37E+5kg

STAGES

Stage Engines Delta V Thrust Burn Mass
2 27 787m/s 14.5MN 1.9m 2.4E+6kg
4 52 7.8km/s 28.0MN 2.4m 1.71E+6kg
