Atlas V is an expendable launch system and the fifth major version in the Atlas launch vehicle family. It was originally designed by Lockheed Martin, now being operated by United Launch Alliance (ULA), a joint venture between Lockheed Martin and Boeing. Atlas V is also a major NASA launch vehicle. It is America's longest-serving active rocket. In August 2021, ULA announced that Atlas V would be retired, and all 29 remaining launches had been sold. As of 6 October 2023, 17 launches remain.
Payload Capacity:
-Payload Capacity to LDO: 8,250 Ton
-Payload Capacity to LPO: 6,420 Ton
-Payload Capacity to GTO: 3,970 Ton
Engine Capacity:
-Total Thrust: 3.8 MN
-Thrust: 1.75MN (RD-180)
-Thrust: 230 KN (Aerojet Rocketdyne RL10)
Atlas V 501 Important Missions:
- X-37B (4 Times Launched)
- Kuiper Project Protoflight (KuiperSat1 and KuiperSat2)
- NROL-41 (USA-215 Spacecraft)
Atlas V 501 Lauching the X-37B OTV
GENERAL INFO
- Created On: Windows
- Game Version: 1.2.109.0
- Price: $46,539k
- Number of Parts: 141
- Dimensions: 52 m x 5 m x 5 m
PERFORMANCE
- Total Delta V: 7.0km/s
- Total Thrust: 31.3MN
- Engines: 9
- Wet Mass: 2.37E+5kg
- Dry Mass: 36,944kg
STAGES
| Stage | Engines | Delta V | Thrust | Burn | Mass |
|---|---|---|---|---|---|
| 1 | 2 | 4.2km/s | 3.7MN | 2.3m | 2.37E+5kg |
| 3 | 0 | 0m/s | 0N | 0s | 25,969kg |
| 4 | 1 | 2.8km/s | 282kN | 2.9m | 25,969kg |
5 Comments
3 Upvotes
Log in in to upvote this post.
I tried my best to replicate this xd
