Orbit 8 is a significantly more capable design within the Orbit series, being purpose-built for the GEO Space Telescope, 'The Eye in the Sky' Mission.
It has a 2.65m core diameter, with the first stage using a single 1,402kN kerolox gas generator, with up to 6 optional 102kN SRBs, and the upper stage using 2 61.8kN hydrolox electric pump-fed engines.
It has a fairing diameter of 3.35m, a total height of 41m, and a maximum payload capacity estimated at 12t to LEO.
The vehicle also has an optional 2-stage solid fueled kick-motor that can be used to carry a maximum of 10t to a somewhat higher LEO. The first kick-motor stage is controlled through RCS thrusters, and the second stage is spin stabilised.
GENERAL INFO
- Created On: Windows
- Game Version: 1.3.204.1
- Price: $9,657k
- Number of Parts: 180
- Dimensions: 41 m x 3 m x 4 m
PERFORMANCE
- Total Delta V: 6.9km/s
- Total Thrust: 2.5MN
- Engines: 15
- Wet Mass: 93,595kg
- Dry Mass: 14,083kg
STAGES
| Stage | Engines | Delta V | Thrust | Burn | Mass |
|---|---|---|---|---|---|
| 1 | 7 | 3.9km/s | 2.3MN | 1.6m | 93,595kg |
| 4 | 2 | 3.0km/s | 124kN | 3.5m | 11,856kg |
| 7 | 0 | 0m/s | 0N | 0s | 7,965kg |
| 8 | 0 | 0m/s | 0N | 0s | 7,965kg |
| 10 | 0 | 0m/s | 0N | 0s | 7,965kg |
